Automatic Potentiometric Titrator AT-710B
Basic Information
1.4K
79
16
Subcategory & Sub-subcategory
Trade Type
Sell
Product Name
Automatic Potentiometric Titrator AT-710B
Manufacturer(s)
Specifications
- Model: AT-710B
- Product configuration: AT-710 + IDP-100 + Propeller stirrer
- Detection range: 1) Potentiometric : -2000mV to +2000mV 2) pH : -20.000 to 20.000pH 3) Temp. : 0 to 100°C
- Titration mode: Auto Titration , Auto Intermit , Intermit , Stat
- Method: 20 (Max 2 methods can be linked)
- Kinds of titration: Potentiometric (acid/base , redox , precipitation) , Photometric , Polarization , Conductivity
- Titration form: Full titration (Auto EP detection) , EP Stop , Level Stop
- Special application: Measurement of electrode potential (pH , potential) , Acid dissociation constant (pKa)
- Key operation: Sheet key
- Displays: 1) White LED-backlit LCD 2) English / Japanese / Mandarin Chinese / Korean / Russian / Spanish 3) 1-channel display
- Calculation: Concentration of content , statistics data processing (mean , SD and RSD) and automatic averaging of blank and factor value
- Data Storage: 50 samples
- GLP conformance: Registration of operator / Record of check results / Record of electrode calibration / Verification of burette capacity / Management of conduction time
- Burette size: 20mL glass burette with brown cover (Standard) Optional burette units : 10mL , 5mL , or 1mL
- Burette accuracy: 50mL burette(Auto dispenser) +/- 0.5mL 20mL burette +/- 0.02mL ; reproducibility +/- 0.01mL 10mL burette +/- 0.015mL ; reproducibility +/- 0.005mL 5mL burette +/- 0.01mL ; reproducibility +/- 0.003mL 1mL burette +/- 0.005mL ; reproducibility +/- 0.001mL
- Preamplifier: 1) STD : pH (mV) and mV , 2 inputs (Standard) 2) PTA : pH (mV) , mV and photometric , 3 inputs 3) POT : pH (mV) , mV and polar , 3 inputs 4) CMT : pH (mV) , mV and conductivity , 3 inputs (factory setting required) 5) TET : pH (mV) 2 ways and mV , inputs
- External I/O: RS-232C port x2 : for Dot matrix printer/Electronic balance/Data Capture Software (SOFT-CAP) SS-BUS x1 : for Multiple sample changer , APB ELE. x1 : for Smart electrode USB x1 : for USB flash drive , Thermal printer , Keyboard , Barcode reader , Foot swit
- Extensibility: Automatic piston burette : Can control max 10 burette drives (Including two built-in burette drives) Multiple sample changer : CHA-700
- Ambient condition: 1) Temperature : 5 to 35°C 2) Humidity : 85%RH or below (no condensation)
- Power source: AC100 to 240V +/- 10% 50/60 Hz
- Power consumption: Main unit : Approx. 20W Printer : Approx. 7W
- Dimensions: Titration unit : 141(W) x 296(D) x 367(H)mm (not incl. tubing) Printer : 106(W) x 180(D) x 88(H) mm
- Weight: Titration unit : Approx. 4.0kg Printer : Approx. 0.4kg
- Conformity standard: CE marking EMC : EN61326-1 LVD : EN61010-1 RE Directive Burette unit EBU FCC Part15 SubpartC FCC ID : 2ABSVEBU01
Other Information
Additional Description:
The AT-710B automatic potentiometric titrator, offered by KYOTO ELECTRONICS MANUFACTURING (Shanghai) Co., LTD, measures potentiometric, pH, and temperature values across industrial, medical, food, and petroleum sample types, with results exportable as PDF to a USB drive and real-time titration curve display on a connected Android device. It supports auto, auto-intermittent, intermittent, and stat titration modes with up to two linked methods, and is a trading-supplied instrument rather than one the supplier manufactures itself.
