Automatic Potentiometric Titrator AT-710S
Manufacturer(s)
Specifications
- Model: AT-710S
- Product configuration: MCU-710S + AT-710 + IDP-100 + Propeller stirrer
- Detection range: 1) Potentiometric : -2000mV to +2000mV 2) pH : -20.000 to 20.000pH 3) Temp. : 0 to 100°C
- Titration mode: Auto Titration , Auto Intermit , Intermit , Stat , Petroleum Titration , COD
- Method: Standard method 120 , Combined method 10 (Max 5 methods can be linked)
- Kinds of titration: Potentiometric (acid/base , redox , precipitation) , Photometric , Polarization , Conductivity
- Titration form: Full titration (Auto EP detection) , EP Stop , Level Stop , Intersect , EP Stop/Level Stop
- Special application: Measurement of electrode potential (pH , potential) , Acid dissociation constant (pKa)
- Key operation: Touch panel
- Displays: 1) 8.4-inch color LCD 800 x 600 dots
- Calculation: Concentration of content , statistics data processing (mean , SD and RSD) and automatic averaging of blank and factor value
- Data Storage: 500 samples
- GLP conformance: Registration of operator / User group administration Titrant : Reminder of date of factor measurement / Alarm to indicate remaining reagent / Reminder of piston replacement date / Reminder of reagent replacement date / History of factor measurement Check
- Burette size: 20mL glass burette with brown cover (Standard) Optional burette units : 10mL , 5mL , or 1mL
- Burette accuracy: 50mL burette(Auto dispenser) +/- 0.5mL 20mL burette +/- 0.02mL ; reproducibility +/- 0.01mL 10mL burette +/- 0.015mL ; reproducibility +/- 0.005mL 5mL burette +/- 0.01mL ; reproducibility +/- 0.003mL 1mL burette +/- 0.005mL ; reproducibility +/- 0.001mL
- Preamplifier: 1) STD : pH (mV) and mV , 2 inputs (Standard) 2) PTA : pH (mV) , mV and photometric , 3 inputs 3) POT : pH (mV) , mV and polar , 3 inputs 4) CMT : pH (mV) , mV and conductivity , 3 inputs (factory setting required) 5) TET : pH (mV) 2 ways and mV , inputs
- External I/O: RS-232C port x3 : for Dot matrix printer/Electronic balance/Data Capture Software (SOFT-CAP) SS-BUS x1 : for Multiple sample changer , APB ELE. x1 : for Smart electrode USB x1 : for USB flash drive , Thermal printer , A4 printer , Keyboard , Barcode reade
- -: LAN ×1 : for Personal computer (PC)
- Ambient condition: 1) Temperature : 5 to 35°C 2) Humidity : 85%RH or below (no condensation)
- Power source: AC100 to 240V +/- 10% 50/60 Hz
- Power consumption: Main unit : Approx. 30W Printer : Approx. 7W
- Dimensions: Touch panel controller : 225(W) x 190(D) x 42(H)mm Titration unit : 141(W) x 296(D) x 367(H)mm (not incl. tubing) Printer : 106(W) x 180(D) x 88(H) mm
- Weight: Touch panel controller : Approx. 1.5kg Titration unit : Approx. 4.0kg Printer : Approx. 0.4kg
- Conformity standard: CE marking EMC : EN61326-1 LVD : EN61010-1 RE Directive Burette unit EBU FCC Part15 SubpartC FCC ID : 2ABSVEBU01
Other Information
Additional Description:
The AT-710S, from KYOTO ELECTRONICS MANUFACTURING (Shanghai) Co., LTD, is a touch-panel potentiometric titrator for industrial, medical, food, and petroleum samples, offering an 8.4-inch color touchscreen, 500-sample data storage, and GLP-conformant record keeping for titrant, electrode, and burette management. It supports simultaneous logging of two potentials (such as pH plus conductivity or temperature) and can link to additional titrators or Karl Fischer moisture titrators for expanded measurement; the supplier is a trading company rather than the manufacturer.
