Automatic Potentiometric Titrator AT-710M
Basic Information
437
15
4
4.2(79)
Subcategory & Sub-subcategory
Trade Type
Sell
Product Name
Automatic Potentiometric Titrator AT-710M
Manufacturer(s)
Specifications
- Model: AT-710M
- Product configuration: MCU-710M + AT-710 + IDP-100 + Propeller stirrer
- Detection range: 1) Potentiometric : -2000mV to +2000mV 2) pH : -20.000 to 20.000pH 3) Temp. : 0 to 100°C
- Titration mode: Auto Titration , Auto Intermit , Intermit , Stat , Petroleum Titration , COD
- Method: Standard method 120 , Combined method 10 (Max 5 methods can be linked)
- Kinds of titration: Potentiometric (acid/base , redox , precipitation) , Photometric , Polarization , Conductivity
- Titration form: Full titration (Auto EP detection) , EP Stop , Level Stop , Intersect , EP Stop/Level Stop
- Special application: Measurement of electrode potential (pH , potential) , Acid dissociation constant (pKa)
- Key operation: Touch panel
- Displays: 1) 8.4-inch color LCD 800 x 600 dots
- Calculation: Concentration of content , statistics data processing (mean , SD and RSD) and automatic averaging of blank and factor value
- Data Storage: 500 samples
- GLP conformance: Registration of operator / User group administration Titrant : Reminder of date of factor measurement / Alarm to indicate remaining reagent / Reminder of piston replacement date / Reminder of reagent replacement date / History of factor measurement Check
- Burette size: 20mL glass burette with brown cover (Standard) Optional burette units : 10mL , 5mL , or 1mL
- Burette accuracy: 50mL burette(Auto dispenser) +/- 0.5mL 20mL burette +/- 0.02mL ; reproducibility +/- 0.01mL 10mL burette +/- 0.015mL ; reproducibility +/- 0.005mL 5mL burette +/- 0.01mL ; reproducibility +/- 0.003mL 1mL burette +/- 0.005mL ; reproducibility +/- 0.001mL
- Preamplifier: 1) STD : pH (mV) and mV , 2 inputs (Standard) 2) PTA : pH (mV) , mV and photometric , 3 inputs 3) POT : pH (mV) , mV and polar , 3 inputs 4) CMT : pH (mV) , mV and conductivity , 3 inputs (factory setting required) 5) TET : pH (mV) 2 ways and mV , inputs
- External I/O: RS-232C port x3 : for Dot matrix printer/Electronic balance/Data Capture Software (SOFT-CAP) SS-BUS x1 : for Multiple sample changer , APB ELE. x1 : for Smart electrode USB x1 : for USB flash drive , Thermal printer , A4 printer , Keyboard , Barcode reade
- LAN ×1 : for Personal computer (PC): LAN ×1
- Extensibility: Measuring instrument : Automatic Potentiometric Titrator (AT-710) , Karl Fischer Moisture Titrator (MKV-710/MKC-710); Three of these instruments can be added.
- Ambient condition: 1) Temperature : 5 to 35°C 2) Humidity : 85%RH or below (no condensation)
- Power source: AC100 to 240V +/-10% 50/60 Hz
- Power consumption: Main unit : Approx. 30W Printer : Approx. 7W
- Dimensions: Touch panel controller : 225(W) x 190(D) x 42(H)mm Titration unit : 141(W) x 296(D) x 367(H)mm (not incl. tubing) Printer : 106(W) x 180(D) x 88(H) mm
- Weight: Touch panel controller : Approx. 1.5kg Titration unit : Approx. 4.0kg Printer : Approx. 0.4kg
- Conformity standard: CE marking EMC : EN61326-1 LVD : EN61010-1 RE Directive Burette unit EBU FCC Part15 SubpartC FCC ID : 2ABSVEBU01
Other Information
Additional Description:
The AT-710M, offered by KYOTO ELECTRONICS MANUFACTURING (Shanghai) Co., LTD, extends the AT-710 titrator platform to simultaneous 4-channel measurement, connecting up to four titrators - including Karl Fischer volumetric or coulometric moisture titrators - for parallel testing of industrial, medical, food, and petroleum samples. It shares the AT-710S's 8.4-inch touch panel, GLP-conformant record keeping, and Bluetooth-linked control unit, and is supplied by a trading company rather than the manufacturer.
