HEATING MACHINE UC series
Basic Information
1.1K
25
22
4.4(63)
Subcategory & Sub-subcategory
Trade Type
Sell
Product Name
HEATING MACHINE UC series
Details
Manufacturer(s)
Specifications
- Model: UC-1820
- Temperature range β: 50β~170β
- Controller: PID adaptive controller
- Temp. control optional: Heat-conducting medium outlet temp. control
- Communication protocol: MODBUS RTU Protocol, RS 485 Interface
- Temperature feedback: Heat-conducting medium temperature feedback PT100
- Temp. accuracy: Β±0.5β
- Heating power: 2kW
- Cooling capacity: 300β
- 200β: 2kW at 170β
- 100β: 1.3kW
- 65β: 0.6kW
- Circulation pump: Max10L/min 0.7BAR
- Heater: Orient electric heater
- Independent Temperature limiter: LNEYA
- Cooler: KAORI Plate heat exchanger
- Operation Panel: Display setting temperature and testing temperature; Touch screen display
- Safety protection: Self-diagnosis function; freezer overload protection; high pressure switch, overload relay, thermal protection device, liquid low level protection, high temperature protection and temperature fault protection.
- Closed circulation system: The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, pressure do not rise up when system is running. The system will supplement oil automatically at low temperature.
- Connection size: DN15
- Weight: 35kg
- Power: AC 220V 50HZ 2.2kW (max)
- Case material: Cold rolled steel
- Optional power: 220V 60HZ three-phase, 440V~480V 60HZ three-phase
Supply Chain
Delivery:
Acceptable Lead Time: 25 days
